بطارية CSB GP12400I 12 فولت 40 أمبير ساعة

Home
/
categories
/
بطارية CSB GP12400I 12 فولت 40 أمبير ساعة

676.20 SR

Quantity (Please contact us to confirm product availability)

+ -

Product description

بطارية CSB GP12400I 12 فولت 40 أمبير ساعة

بطارية CSB GP12400I 12 فولت 40 أمبير ساعة مخصص لـاختيار مصدر طاقة متوافق مع الجهد والسعة ومتطلبات الجهاز. راجع المواصفات والتوافق لتحديد ملاءمته لمهمتك قبل الشراء.

الهوية والاستخدام

نوع المنتج: بطارية.
مرجع الاختيار: CSB GP12400I.
الاستخدام: اختيار مصدر طاقة متوافق مع الجهد والسعة ومتطلبات الجهاز.

كيف تختار المنتج المناسب؟

طابق الجهد والسعة والأبعاد ونوع الأطراف مع جهازك وشاحنك. تشابه الجهد وحده لا يضمن التوافق.

للمشترين في السعودية

قارن CSB GP12400I لدى شركة الصندوق الآمن SafeBox وفق احتياجك الفني والمواصفات الموضحة، واستخدم رقم الموديل عند طلب مطابقة المنتج.

التفاصيل الفنية الأصلية باللغة الإنجليزية

GP12400

12 V	40.0Ah
GP 12400 is a general purpose battery up to 5 years in standby service or more than 260 cycles at 100% discharge in cycle service. As with all CSB batteries, all are rechargeable, highly efficient, leak proof and maintenance free.

Download :

GP12400 Spec Sheet-(749.21K)

Specification

Cells Per Unit

Voltage Per Unit

12 V

Capacity

40 Ah @ 20hr-rate to 1.75V per cell @ 25°C (77°F)

Weight (kg)

Approx. 12.63 kg. (27.84 lbs.)

Maximum Discharge current (A)

400 A (5sec.)

Internal Resistance Approx.

Approx. 8.5 mΩ

Operating Temperature Range

Discharge：-15℃~50℃(5°F~122°F)
Charge：-15℃~40℃(5°F~104°F)
Storage：-15℃~40℃(5°F~104°F)

Nominal Operating Temperature Range

25°C ± 3°C (77°F ± 5°F)

Float charging voltage

13.5 to 13.8 VDC/unit Average at 25°C (77°F)

Recommended Maximum Charging current limit

12 A

Equalization and Cycle Service

14.4 to 15.0 VDC/unit Average at 25°C (77°F)

Self Discharge

It should be more than 75% of the capacity that before storage after stocked for 6 months at ambient temp. 25℃

Terminal

B8 -L terminal (M5 bolt) or Recessed type (M6 bolt)

Container Material

ABS(UL94-HB) & Flammability resistance of(UL94-V0) can be available upon request.

Dimensions

Constant Current Discharge Characteristics Unit:Amperes (25°C,77°F)

F.V/Time	5MIN	10MIN	15MIN	30MIN	60MIN	90MIN	2HR	3HR	5HR	8HR	10HR	20HR
1.60V	176.00	113.00	85.00	51.80	30.60	22.20	17.70	12.60	8.01	5.25	4.28	2.21
1.67V	157.00	105.00	81.00	50.80	30.30	22.10	17.60	12.50	7.98	5.19	4.19	2.11
1.70V	149.00	101.00	78.70	50.10	30.20	21.90	17.50	12.40	7.96	5.17	4.16	2.08
1.75V	135.00	95.00	75.50	49.00	30.00	21.80	17.40	12.30	7.93	5.10	4.09	2.00
1.80V	121.00	88.30	71.70	47.60	29.80	21.70	17.30	12.20	7.88	5.03	4.03	1.93
1.85V	107.00	81.70	67.80	46.20	29.40	21.50	17.20	12.10	7.85	4.96	3.96	1.85

Constant Power Discharge Characteristics Unit:Watts (25°C,77°F)

F.V/Time	5MIN	10MIN	15MIN	30MIN	60MIN	90MIN	2HR	3HR	5HR	8HR	10HR	20HR
1.60V	2110.00	1350.00	1020.00	622.00	367.00	266.00	212.00	151.00	96.10	63.00	51.30	26.50
1.67V	1886.00	1259.00	972.00	606.00	364.00	264.00	211.00	150.00	95.70	62.30	50.40	25.40
1.70V	1790.00	1214.00	945.00	600.00	363.00	263.00	210.00	149.00	95.50	62.00	50.00	24.90
1.75V	1620.00	1140.00	902.00	585.00	360.00	262.00	209.00	148.00	95.20	61.20	49.20	24.10
1.80V	1450.00	1060.00	860.00	571.00	357.00	260.00	208.00	147.00	94.80	60.40	48.30	23.20
1.85V	1280.00	980.00	814.00	555.00	353.00	258.00	207.00	146.00	94.20	59.60	47.50	22.40
