High Voltage Insulation Tester

Product description

Dual scales for low and high ranges which change automatically. Colour coded scales for easy reading plus LED’s that illuminate in matching colour.
•	Drip proof construction.
•	Hard carrying case furnished as standard accessory.
•	Designed for low power consumption.

MODEL	3121	3122	3123
DC Test Voltage	2500V	5000V	5000V	10000V
Measuring Ranges (automatic change)	2GΩ/100GΩ (autoranging)	5GΩ/200GΩ (autoranging)	5GΩ/200GΩ (autoranging)	10GΩ/400GΩ (autoranging)
First Effective Measuring Ranges Accuracy	0.1 - 50GΩ	0.2 - 100GΩ	0.2 - 100GΩ	0.4 - 200GΩ
	\|±5% rdg
Other ranges Accuracy	\|±10% rdg or 0.5% of scale length
Withstand Voltage	5000V AC for 1 minute
Power Source	R6 (AA) (1.5V) × 8
Dimensions	200(L) × 140(W) × 80(D)mm
Weight	1kg approx.
Accessories	7058 (Test leads) 9039 (Carrying case [Hard]) R6 (AA) × 8 Instruction Manual		7058 (Test leads) 9039 (Carrying case [Hard]) 8019 (Hook type prod) R6 (AA) × 8 Instruction Manual
Optional	8019 (Hook type prod) 8020 (Adaptor for recorder)		8020 (Adaptor for recorder)
